NIM MODULES
![blog-image](https://brilliantelectronics.com/storage/product/fcc1e3aacd1660827979.png)
Product Enquiry
Product Features
The NCB234 is a passive dual sections delay unit housed in a single unit NIM module. Each section delay a signal in range 0 up 63,5 ns with a 1,6 ns offset. Common delay can be installed from 0 to 127 ns. The module is made of calibrated coaxial cable to rich high accuracy delay during measurement. Each section has 0,5 ns resolution and accuracy of delay is 100 ps in full range. Each channel has seven switches on the front panel of module to select delays. Attenuation of signal in bandwidth 200 MHz is less then 1,5 dB in delay range up to 15,5 ns and 4,5 dB in full delay range.
Part Descriptions
NCB9
NCB10
NCB210
NCB211
NCB211A
NCB212F
NCB213
NCB214
NCB215
NCB215P
NCB216
NCB217
NCB218
NCB219
NCB221
NCB222
NCB223
NCB226
NCB228
NCB231
